HP Z2 Mini G5 Workstation
HP Z2 Mini G5 Workstation
Enterprise stock · tested · export documentation available
HP Z2 Mini G5 Workstation Overview & Specifications
Overview
The HP Z2 Mini G5 is a ultra-compact workstation built for high-performance workflows (CAD, 3D design, rendering, and data analysis). Designed with tool-less chassis access and flexible mounting options (VESA mount, rack mount, or under-desk).
Technical Specifications
| Feature | Specification Details |
| Form Factor | Mini Workstation (Desktop) |
| Dimensions (W × D × H) | 8.5 × 8.5 × 2.28 in / 21.6 × 21.6 × 5.8 cm |
| Weight | Starting at 4.6 lbs / 2.1 kg (varies by configuration) |
| Chipset | Intel® W480 Chipset |
| Processors (10th Gen) |
• Intel® Core™: i3-10100 / i5-10500 / i7-10700 / i7-10700K / i9-10900 / i9-10900K • Intel® Xeon® W-Series: W-1250 / W-1270 / W-1290 / W-1290P (vPro support) |
| Memory |
• 2 SODIMM slots • Up to 64GB DDR4-3200 MT/s (ECC supported with Intel® Xeon® processors) |
| Internal Storage |
• Up to 2× M.2 2280 NVMe PCIe SSD (HP Z Turbo Drive) • 1× 2.5-inch SATA HDD/SSD bay |
| Graphics |
• Integrated: Intel® UHD Graphics 630 / P630 • Discrete (MXM slot): NVIDIA® Quadro® P620 (4GB GDDR5), T1000, T2000, or RTX™ 3000 (6GB GDDR6) |
| Power Supply | External power adapter options: 180W or 280W (up to 90% efficiency, active PFC) |
| Operating Systems | Windows 11 Pro, Windows 10 Pro 64-bit, Ubuntu Linux, Red Hat Enterprise Linux certified |
Ports & Expansion Options
Side I/O Ports
-
1× Headphone/Microphone Combo Jack
-
2× SuperSpeed USB Type-A 10Gbps signaling rate
-
1× SuperSpeed USB Type-C® 10Gbps signaling rate
Rear I/O Ports
-
2× DisplayPort™ 1.4 (Standard)
-
2× SuperSpeed USB Type-A 10Gbps signaling rate
-
1× RJ-45 Ethernet Port (Gigabit LAN)
-
1× Power Connector
-
Flex I/O Module Slot (Configurable Option): Choice of additional DisplayPort™, HDMI 2.0b, VGA, Serial Port, 2nd 1GbE LAN, 2.5GbE LAN, or Thunderbolt™ 3
Connectivity & Security
-
Wireless: Intel® Wi-Fi 6 AX201 (2×2) and Bluetooth® 5 combo
-
Security: TPM 2.0, HP Sure Start Gen6, HP Sure Sense, HP Client Security Manager Gen6, Cable Lock Slot
