HP ProLiant DL360p Gen8 Server 1U Rackmount
DL360p Gen8
Enterprise stock · tested · export documentation available
HP ProLiant DL360p Gen8 Server Overview
The HP ProLiant DL360p Gen8 is a dense 1U, dual-socket rack server designed for enterprise workloads, virtualization, and high-performance computing. Built on Intel Xeon E5-2600 and E5-2600 v2 product families, it delivers high compute density, flexible network connectivity, and advanced system management via HP iLO 4.
Technical Specifications
System Architecture
| Parameter | Specification |
| Form Factor | 1U Rackmount |
| Processor Sockets | 2 Sockets (LGA 2011) |
| Supported CPUs | Intel® Xeon® E5-2600 & E5-2600 v2 Series (Up to 12 cores per processor, TDP up to 135W) |
| Chipset | Intel® C600 Series Chipset |
| System Bus | Intel® QuickPath Interconnect (QPI) up to 8.0 GT/s |
Memory
| Parameter | Specification |
| DIMM Slots | 24 Slots (12 DIMMs per processor / 4 Channels per processor) |
| Memory Types | DDR3 Registered (RDIMM), Load-Reduced (LRDIMM), Unbuffered (UDIMM) |
| Maximum Capacity (LRDIMM) | Up to 768 GB (24 x 32GB @ 1866 MHz) |
| Maximum Capacity (RDIMM) | Up to 384 GB (24 x 16GB @ 1866 MHz) |
| Maximum Capacity (UDIMM) | Up to 128 GB (16 x 8GB @ 1333 MHz) |
| Memory Protection | Advanced ECC, Online Spare, Memory Lock-step Mode |
Storage & Controllers
| Parameter | Specification |
| Drive Bay Configurations |
• 4 LFF (3.5-inch) Hot-Plug SAS/SATA/SSD • 8 SFF (2.5-inch) Hot-Plug SAS/SATA/SSD • 10 SFF (2.5-inch) Hot-Plug SAS/SATA/SSD |
| Onboard Controller | HP Smart Array P420i Controller |
| Storage Cache | Optional ZM (Zero Memory), 512MB, 1GB, or 2GB Flash-Backed Write Cache (FBWC) |
| RAID Support | RAID 0, 1, 10, 5, 50, 6, 60 (depends on installed FBWC) |
| Optical Drive | Optional Slimline DVD-ROM / DVD-RW Bay (available on select drive cages) |
Networking & Expansion
| Parameter | Specification |
| Network Adapter | HP FlexibleLOM Slot (Choice of 4x 1GbE 331FLR or 2x 10GbE 530FLR-SFP+ / 10Base-T) |
| PCIe 3.0 Slots |
Slot 1: PCIe 3.0 x16 (Full-Height, Half-Length) Slot 2: PCIe 3.0 x8 (Low Profile) |
| I/O Interfaces |
• VGA Video: 2 (1 Front via Adapter Kit, 1 Rear) • USB 2.0: 7 total (2 Front, 4 Rear, 1 Internal) • Serial Port: 1 Rear • SD Slot: 1 Internal Secure MicroSD • iLO Management: 1 Dedicated 1GbE Port |
Management & Reliability
| Parameter | Specification |
| Remote Management | HP iLO 4 (Integrated Lights-Out 4) Management Engine |
| Health Monitoring | HP Active Health System & 3D Array of Thermal Sensors |
| Diagnostics | Slide-out System Insight Display (SID) panel |
| Cooling | Redundant hot-plug fan modules (6 fans for 1 CPU, 8 fans for 2 CPUs) |
Power Supply & Physical Dimensions
| Parameter | Specification |
| Power Supplies | Dual Hot-Plug Redundant Common Slot Power Supplies (460W / 750W / 1200W, 94%+ Platinum/Titanium efficiency) |
| Dimensions (H x W x D) | 1.7″ x 17.1″ x 27.5″ (4.32 cm x 43.46 cm x 69.85 cm) |
| Weight | ~17.4 kg to 19.2 kg (38.3 lbs to 42.3 lbs depending on configuration) |
